Fully Automatic Chemistry Analyzer
Model:EM380Plus
SKU00773
The EastMed EM380Plus Fully Automatic Chemistry Analyzer delivers 300 tests/hour with double-reagent efficiency, ideal for mid-to-high volume labs. Featuring 70 reagent positions, 90 reaction cuvettes, and 8 wavelength options (340nm–700nm), it ensures precision with 0.1µL sample dosing and 37°C±0.1°C temperature control. Its open-system design supports any reagent, while barcode reading (optional) and collision avoidance streamline workflow. Perfect for colorimetric, turbidimetry, and kinetic testing with Windows OS compatibility.
| Category | Specifications |
|---|---|
| Model | EastMed EM380Plus |
| Test Speed | 300 tests/hour (double reagent) |
| Test Methods | Colorimetric, Turbidimetry, 1/2-point end, Fixed-Time, Kinetics |
| Sample Capacity | 70 positions (tubes/cups: 12–13mm × 25–100mm) |
| Reagent Capacity | 70 positions (2°C–14°C cooling via Peltier) |
| Sample Volume | 2–30µL (0.1µL steps) |
| Reagent Volume | 20–300µL (1µL steps) |
| Wavelengths | 340nm, 405nm, 450nm, 505nm, 546nm, 578nm, 630nm, 700nm (+4 optional) |
| Reaction System | 90 cuvettes, 150–330µL volume, 37°C±0.1°C |
| Calibration | Linear/nonlinear, up to 8-point |
| Software | Windows XP/7/8/10, QC (Westgard rules) |
| Dimensions | 920mm × 650mm × 1120mm (L×W×H), 170kg |
| Power | AC 110V/220V ±10%, 650W |
Key Features & Benefits
-
High Efficiency: 300 tests/hour with double-reagent support.
-
Precision: 0.1µL sample dosing and ±0.1°C temperature control.
-
Open System: Compatible with any reagent (locked reagent optional).
-
Advanced Optics: 8 wavelengths + 4 optional for versatile assays.
-
Low Carry-Over: Teflon-coated mixer and probe collision avoidance.
-
User-Friendly: Barcode reader (optional), automatic calibration, and Windows OS software.
-
Cost-Effective: 90 reusable cuvettes and low sample/reagent consumption.
-
