Semi-Auto Biochemistry Analyzer – Features, Specifications & Benefits

A semi-auto biochemistry analyzer is a versatile and cost-effective diagnostic tool designed for clinical laboratories. This advanced instrument combines clinical chemistry, turbidimetry, coagulation testing, and multipurpose incubation in a single system, offering 4 key benefits at the cost of 1.

Key Features of the Semi-Auto Biochemistry Analyzer

Feature	Description
Multi-Analysis Modes	Convenient selectable reading modes for Flow cell, Cuvette & Tube analysis
User-Friendly Operation	Easy & fast operation via Touch Screen, Mouse, Keyboard & Barcode Reader
High Accuracy & Precision	Long-life 8 IAD Filters (340nm - 670nm) ensure reliable results
Enhanced Visibility	7.0" True Color Touch Screen for better operation & readability
Reduced Contamination	Air purge between samples prevents carryover & Lamp saver mode for efficiency

Technical Specifications

Optical Unit

8 IAD Interference Filters: 340, 405, 450, 505, 546, 578, 630 & 670 nm
Detector: Silicon Photodiode
Photometric Range: 0 to 3 OD
Resolution: 0.0001A
Light Source: Halogen Lamp

Measuring Unit

Triple Cuvette Analysis: 18µl Quartz Flow cell, 10mm Square Cuvette, 6mm Round Tube
Temperature Control: Peltier-based (25°C, 30°C, 37°C & RT)
Minimum Aspiration Volume: 200µl via Peristaltic Pump
26-Position Incubator: Inbuilt at 37°C

Analysis Methods

Endpoint with Reagent Blank
Two Point End
Kinetic
Fixed Time (Two Point)
Turbidimetry & Coagulation Testing

Calibration Modes

Bi-Chromatic Filter Selection
Linear & Non-Linear Calibration (1Pt, 2Pt, Multipoint, Logit-Log, Exponential, Parabola)

Memory & Software

300 User-Defined Test Programs
200,000 Sample Results Storage
Multi-Level QC with Levy-Jennings Graphs
Patient ID & Name Entry
Result Recall by Date, Name & ID

Connectivity & Display

7.0" True Color Touch Screen
Input/Output: 4 USB, Slave USB, Ethernet (Keyboard, Mouse, Barcode Reader)
Built-in Thermal Printer

Power & Dimensions

Power Supply: 19V DC / 90W (90-264V AC, 50/60Hz)
Dimensions: 400(L) x 300(W) x 191(H) mm
Weight: 7 kg

Why Choose a Semi-Auto Biochemistry Analyzer?

Affordable Price: A cost-effective alternative to fully automated systems.
Flexible Operation: Supports multiple analysis modes (flow cell, cuvette, tube).
Reliable Performance: High-precision optical system with long-lasting filters.
User-Friendly: Intuitive touch screen & barcode reader for quick operation.

Semi Auto Analyser Principle

The semi-auto biochemistry analyzer works on photometric principles, measuring absorbance at different wavelengths to determine analyte concentrations. Its peristaltic pump and Peltier temperature control ensure accurate and reproducible results.

Semi Auto Biochemistry Analyzer Price

The price of a semi-auto biochemistry analyzer varies based on features, but this model offers high-end performance at a competitive cost, making it ideal for small to medium labs.
